*Bishamon BS-55 Hydraulic Unit

*Bishamon BS-55 Hydraulic Unit

Identify your part using this line drawing of the Hydraulic Unit.

Locate a part on the frame.

  1. BI 02103814 Handle Frame
    BI 02103804 Handle Assembly
    BI 02108950 Handle Assembly
  2. BI 90980622 Roll Pin
  3. BI 52103804 Handle Cap
  4. BI 12003943 Control Lever
  5. BI 90980514 Roll Pin
  6. BI 12003953 Locking Lever
  7. BI 12103964 Control Rod
  8. BI 80839000 Master Link
  9. BI 02008474 Chain w/ Rod
  10. BI 52003983 Spring Clip
  11. BI 90930708 Washer
  12. BI 90931508 Adjusting Nut
  13. Not Available
  14. BI 90930106 Nut
  15. BI 90930506 Lock Washer
  16. BI 12003973 Nut
  17. BI 80830004 Chain
  18. BI 12003983 Lower Control Rod
  19. BI 12003913 Handle Bolt (RH)
  20. BI 12003923 Handle Bolt (LH)
  21. BI 90820530 Roll Pin
  22. BI 12003914 Handle Pin
  23. BI 12003853 Pin
  24. BI 90980325 Roll Pin
  25. BI 12003843 Roller
  26. BI 81710121 Bushing
  27. BI 81916201 Bushing
  28. BI 12003463 Screw Plug
  29. BI 80800411 O-Ring
  30. BI 52003493 Spring
  31. BI 12003473 Valve
  32. BI 12003483 Valve Seat
  33. BI 80800005 O-Ring
  34. BI 80843022 Ball
  35. BI 90980835 Roll Pin
  36. BI 52003463 Spring
  37. BI 12003493 Release Pin
  38. BI 80800002 O-Ring
  39. BI 80800010 O-Ring
  40. BI 12003503 Release Pin Guide
  41. BI 52003513 Rubber Bushing
  42. BI 12003513 Foot Pedal
  43. BI 90962820 Set Screw
  44. BI 90930308 Nut
  45. BI 80800260 O-Ring
  46. BI 12003533 Filler Plug
  47. BI 80800023 O-Ring
  48. BI 12003633 Pump Cylinder
  49. BI 52003643 U-Cup
  50. BI 12003645 Piston
  51. BI 52003633 Scraper
  52. BI 52103653 Spring
  53. BI 12003653 Spring Cap
  54. BI 80848009 Snap Ring
  55. BI 12003604 Bearing Cup
  56. BI 80845015 Snap Ring
  57. BI 81251205 Thrust Bearing
  58. BI 12003593 Thrust Collar
  59. BI 80846031 Snap Ring
  60. BI 80846037 Snap Ring
  61. BI 52103553 Scraper
  62. Not Available
  63. BI 12049564 Ram
  64. See Bishamon Seal Kits
  65. BI 12013574 Piston Bushing
  66. BI 52013563 U-Cup
  67. BI 12003583 Washer
  68. BI 52103663 Spring
  69. BI 12103613 Ball Seat
  70. BI 80800006 O-Ring
  71. BI 80843015 Ball
  72. BI 12103624 Relief Seat
