Bishamon

*Bishamon BS-55 Frame

Identify your part using this line drawing of the frame.

Locate a part on the hydraulic unit.

  1. BI 12007244 Lifting Link Shaft
  2. BI 90980530 Roll Pin
  3. BI 12003683 Bearing Cover
  4. BI 81251109 Traverse Bearing
  5. BI 12013674 - Please call for Pricing and Availability
  6. BI 81940442 Bushing
  7. BI 12003693 Washer
  8. BI 80845025 Snap Ring
  9. BI 80848009 Snap Ring
  10. BI 12103784 Pin
  11. BI 02103774 Steer Wheel Axle
  12. BS 6005 ZZ Bearing
    BI 81036205 Bearing (OEM Steer Wheel Only)
  13. Steer Wheel Assembly Options
  14. BI 80845011 Snap Ring
  15. BI 12003753 Hub Cap
  16. BI 90890512 Bolt & Washer
  17. BI 12003710-1 Axle
  18. BI 90980845 Roll Pin
  19. BI 81046204 Bearing
    BI 81036004 Bearing (For OEM 2-3/4" Load Roller Only)
    BI 81026304 Bearing (For OEM Steer Wheel Only)
  20. BI 52103690 Sleeve
  21. BI 80846026 Snap Ring
  22. No Longer Available
  23. BI 81920263 Bushing, 20- 1/2" Wide Jack
    BI 81922283 Bushing, 27" Wide Jack (Newer Style)
    BI 81920283 Bushing, 27" Wide Jack
  24. BI 81916201 Bushing
  25. BI 12003703 Shoulder Pin
  26. BI 81920243 Bushing
  27. BI 80847015 Snap Ring
  28. BI 02108264 Push Rod, 48" Forks (Newer Style)
  29. BI 81920241 Bushing
  30. BI 12003293 Push Rod Axle
  31. BI 90980540 Roll Pin
  32. BI 12003313 Pivot Axle
  33. BI 12103433 Exit Roller
  34. BI 02103304 Load Roller Bracket (Newer Style)
  35. BI 12003333 Load Roller Axle
  36. Load Roller Assembly Options
  37. BI 52008153 Bolt
  38. BI 52008143 Entry Roller
  39. BI 90931508 Adjusting Nut
  40. BU 25mm Spacer
  41. BU 47mm HC Hub Cap
  42. BI 12003710-2 Axle
