Clark

*Clark CJ55 Hydraulic Unit

Identify your part using this line drawing of the Hydraulic Unit.

Locate a part on the frame.

  1. CL 1808101 Handle Spring
  2. CL 1808102 Roll Pin
  3. CL 1808103 Roll Pin
  4. CL 1808104 Roll Pin
  5. CL 1808105 Roll Pin
  6. CL 1808106 Roll Pin
  7. CL 1808107 Control Lever
  8. CL 1808263 Handle Assembly Complete
  9. CL 1808109 Handle Roller Pin
  10. CL 1808110 Roll Pin
  11. CL 1808111 Pressure Roller
  12. CL 1808112 Handle Roller Bushing
  13. CL 1808113-A Control Rod Assembly, Includes Lever #7
  14. CL 1808114 Handle Bushing
  15. CL 1808115 Chain
  16. CL 1808116 Adjustment Nut
  17. CL 1808140 Lever Plate Bolt
  18. CL 1808154 Retaining Ring
  19. CL 1808117 Screw
  20. CL 1808153 Lock Washer
  21. CL 1808118 Handle Pivot Pin
  22. CL 1808147 Pump Piston
  23. CL 1808148 Spring Cap
  24. CL 1808149 Handle Return Spring
  25. CL 1808150 Wiper
  26. CL 1808151 U-Cup
  27. CL 1808262 Pump Assembly Complete, Inc 17-34 & 36-56
  28. CL 1808119 Screw Plug
  29. CL 1808120 Seal Washer
  30. CL 1808121 Spring
  31. CL 1808122 Valve Spindle
  32. CL 1808123 Valve Seat
  33. CL 1808124 Chrome Ball
  34. CL 1808146 Chrome Ball
  35. CL 1808152 Lift Piston
  36. CL 1808145 Wiper
  37. CL 1808144 O-Ring
  38. CL 1808143 Cylinder Cap
  39. CL 1808142 O-Ring
  40. CL 1808141 U-Cup
  41. CL 1808126 Seal Washer
  42. CL 1808127 Bolt
  43. CL 1808139 Chrome Ball
  44. CL 1808138 Ball Valve Seat
  45. CL 1808137 Spring
  46. CL 1808136 Bolt
  47. CL 1808128 Spring
  48. CL 1808129 Strike Pin
  49. CL 1808130 O-Ring
  50. CL 1808131 Sleeve
  51. CL 1808132 O-Ring
  52. CL 1808135 Lever Plate
  53. CL 1808134 Nut
  54. CL 1808133 Adjustment Screw
  55. CL 1808264 Steer Wheel Axle
  56. CL 1808265 Steer Wheel Axle Bolt
  57. CL 1808311 Nut
  58. Steer Wheel Assemblies
  59. CL 1808273 Bearing
  60. CL 1808274 Locking Ring, Half Round
  61. CL 1808275 Washer
  62. CL 1808276 Snap Ring
  63. CL 1808277 Hub Cap
  64. CL 1808266 Thrust Bearing
  65. CL 1808267 Thrust Plate
  66. CL 1808268 Roll Pin
  67. CL 1808269 Snap Ring
  68. CL 1808155 Seal Kit
