*Dayton 3KR84 Hydraulic Unit

Identify your part using this line drawing of the Hydraulic Unit.

Locate a part on the frame.

1. WW PM-1HB Shoulder Bolt
2. WW PM-2HB Bushing
3. WW PM-3HB Handle Bracket
4. WW PM-4HB Lock Washer
5. WW PM-5HB Bolt
6. WW PM-6HB Handle Frame
   WW PM-HCA-B Handle Assembly
7. WW PM-7HB Roll Pin
8. WW PM-8HB Roll Pin
9. WW PM-9HB Control Lever
   WW PM-CLK Control Linkage Assembly
   Includes Items 7,9,10, 12-15
10. WW PM-11HB Control Rod
11. WW PM-12HB Roll Pin
12. WW PM-13HB Pin, Chain Link
13. WW PM-14HB Chain
14. WW PM-15HB Ajustment Pin
15. WW PM-16HB Ajustment Nut
16. WW PM-17HB Pin, Pressure Roller
17. WW PM-18HB Pressure Roller
18. WW PM-19HB Roll Pin
19. WW PM-20HB Spring
20. WW PM-21HB Spring Plate
21. WW PM-1P Hub Cap
22. WW PM-2P Snap Ring
23. WW PM-3P Axle
24. WW PM-4P Bearing
25. Steer Wheel Assembly Options
26. WW PM-6P Washer
27. WW PM-7P Release Pin
28. WW PM-8P O-ring
29. WW PM-9P Spring
30. WW PM-10P Nylon Washer
31. WW PM-11P Srew Plug
32. WW PM-12P U-cup
33. WW PM-13P U-cup
34. WW PM-14P Wiper
35. WW PM-15P Lift Ram
36. WW PM-16P Ball
37. WW PM-17P Snap Ring
38. WW PM-18P Spring Cap
39. WW PM-19P Pump Piston
40. WW PM-20P Spring
41. WW PM-21P Wiper
42. WW PM-22P U-cup
43. WW PM-23P Roll Pin
44. WW PM-24P Chain Roller
45. WW PM-25P Valve Plug
46. WW PM-26P O-ring
47. WW PM-27P Spring
48. WW PM-28P Valve Ball
49. WW PM-29P O-ring
50. WW PM-30P Ball
51. WW PM-31P Pin
52. WW PM-32P Roll Pin
53. WW PM-33P Release Lever
54. WW PM-34P Pivot Pin
55. WW PM-35P Thrust Bearing
56. WW PM-36P Snap Ring
57. WW PM-37P Hydraulic Pump Assembly, Rebuilt
57. WW PM-PCA Hydraulic Pump Assembly, New
58. WW PM-38P Snap Ring
59. WW PM-39P Set Screw
60. WW PM-41P Adjustment Bolt
61. WW PM-42P Overload Spring
62. WW PM-43P Plunger
63. WW PM-44P Check Ball
64. WW PM-45P Plug Bolt
65. WW PM-46P O-ring

Kits & Pumps:

• WW PM-SK Seal Kit
