  • Mighty Lift ML55-II & ML55L Frame Line Drawing
1 of 1

Mighty Lift

*Mighty Lift ML55-II & ML55L Frame

Identify your part using this line drawing of the frame.

Locate a part on the hydraulic unit.

  1. ML A201 Frame
  2. ML A202 Bolt
  3. ML A203 Lifting Link
  4. ML A204 Bushing
  5. ML A205 Shaft
  6. ML A206 Bushing
  7. ML A208 Snap Ring
  8. ML A209 Joint
  9. ML A210 Pin
  10. ML A211 Nut
  11. ML A212 Push Rod
  12. ML A213 Snap Ring
  13. ML A214 Shaft
  14. ML A216 Shaft
  15. ML A217 Exit Roller
  16. ML A218 Exit Roller
  17. ML A219 Roll Pin
  18. ML A220 Roll Pin
  19. ML A221 Shaft
  20. ML A222 Load Roller Bracket
  21. ML A225 Washer
  22. ML B009 Bearing
  23. Load Wheel Assembly Options
  24. ML A230 Roll Pin
  25. ML A231 Bolt
  26. ML A232 Entry Roller
  27. ML A233 Locking Nut
  28. ML A235 Load Wheel Axle
  29. ML A236 Washer
  30. ML A237 Lube Fitting

This item is either out of stock or cannot be ordered online. Please call to confirm price, availability, and/or freight costs.
